NUC100-N100 VER:1.0
Model: NUC100-N100
NUC100-N100 VER:1.0 is an industrial computing motherboard designed for mission-critical deployments. Powered by Intel® Alder Lake N100 0.8GHz4 Cores Processor, supports DDR4 memory slot, 3200MHz/1.2V Up to 32GB, equipped with 2 × Gigabit Ethernet RJ45 ports, engineered for industrial automation, network security and edge computing.
System Core Specifications
- CPU: Intel® Alder Lake N100 0.8GHz4 Cores Processor
- Memory: DDR4 memory slot, 3200MHz/1.2V Up to 32GB
- Networking: 2 × Gigabit Ethernet RJ45 ports
- Display: HDMI1+HDMI2+DP Display
- Power: 12V DC Input
- Operating System: Windows 10, Windows 11, Linux (Ubuntu, CentOS)
- Operating Temp: 0 ~ 60 °C (Industrial Standard)
Product overview
Technical specifications
NUC100-N100 VER:1.0 Technical Specifications
| Category | Sub-item | Specifications |
|---|---|---|
| Processor System | CPU Processor | Intel® Alder Lake N100 0.8GHz4 Cores Processor |
| Architecture | Compatible with Alder Lake-N series:N95, N97, N150, N200 and other options | |
| System Memory | Slots & Capacity | DDR4 memory slot, 3200MHz/1.2V Up to 32GB |
| Display Graphics | Display Outputs | HDMI1+HDMI2+DP Display |
| Multi-Display | Multi-screen independent synchronous/asynchronous display output | |
| Ethernet & I/O | Ethernet LAN | 2 × Gigabit Ethernet RJ45 ports |
| Serial Ports (COM) | 1 × Serial Ports (RS-232, optional RS-485) | |
| Expansion Slots | Expansion Busses | 1 M.2 2230 WIFI slot; supports 1 M.2 2280 slot (supports NGFF/NVME mode) |
| Storage & USB | Storage | 1 M.2 2280 slot (supports NGFF/NVME mode) |
| USB Ports | 5 × USB Ports, 1 TYPE-C interface | |
| Reliability | Hardware Programmable Watchdog Timer, One-Key CMOS Clear | |
| Mechanical & Power | Power Input | 12V DC Input |
| Dimensions | 120*120mm | |
| Operating Temp | 0 ~ 60 °C (Industrial Standard) | |
| Supported OS | Windows 10, Windows 11, Linux (Ubuntu, CentOS) |
Downloads
No download files are attached to this product. You can request documents from our engineers.
Frequently Asked Questions
Technical specifications, OS compatibility, and deployment details for this platform
What processor and memory are listed for NUC100-N100?
Processor: Intel® Alder Lake N100 0.8GHz4 Cores Processor; Memory: DDR4 memory slot, 3200MHz/1.2V Up to 32GB
What interfaces are listed for NUC100-N100?
Network: 2 × Gigabit Ethernet RJ45 ports; Display: HDMI1+HDMI2+DP Display
What operating conditions and software are listed for NUC100-N100?
Power input: 12V DC Input; Operating temperature: 0 ~ 60 °C (Industrial Standard); Operating system: Windows 10, Windows 11, Linux (Ubuntu, CentOS)
