AX86M-LV62-HM86 VER:1.0
Model: AX86M-LV62-HM86
AX86M-LV62-HM86 VER:1.0 is an industrial computing motherboard designed for mission-critical deployments. Powered by Intel® I5-43000M 2.6GHz 2 Cores / 4 Threads Processor, supports 2×SO-DIMM DDR3 memory, Up to 16GB, equipped with 2 × Gigabit Ethernet RJ45 ports (Single-LAN optional), engineered for industrial automation, network security and edge computing.
System Core Specifications
- CPU: Intel® I5-43000M 2.6GHz 2 Cores / 4 Threads Processor
- Memory: 2×SO-DIMM DDR3 memory, Up to 16GB
- Networking: 2 × Gigabit Ethernet RJ45 ports(Single-LAN optional)
- Display: LVDS/EDP1+VGA/EDP2+HDMIDisplay
- Power: 12V DC Input
- Operating System: Windows 10, Windows 11, Linux (Ubuntu, CentOS)
- Operating Temp: 0 ~ 60 °C (Industrial Standard)
Product overview
Technical specifications
AX86M-LV62-HM86 VER:1.0 Technical Specifications
| Category | Sub-item | Specifications |
|---|---|---|
| Processor System | CPU Processor | Intel® I5-43000M 2.6GHz 2 Cores / 4 Threads Processor |
| Architecture | Compatible with 4100M/4200M/4600M and other options | |
| System Memory | Slots & Capacity | 2×SO-DIMM DDR3 memory, Up to 16GB |
| Display Graphics | Display Outputs | LVDS/EDP1+VGA/EDP2+HDMIDisplay |
| Multi-Display | Multi-screen independent synchronous/asynchronous display output | |
| Ethernet & I/O | Ethernet LAN | 2 × Gigabit Ethernet RJ45 ports(Single-LAN optional) |
| Serial Ports (COM) | 6 × Serial Ports (RS-232, optional RS-485) (optional 2 serial ports) | |
| Expansion Slots | Expansion Busses | 1 Mini-PCIE (supports 4G module and WIFI module); supports 1 MSATA SSD slot |
| Storage & USB | Storage | 1 × mSATA SSD Slot |
| USB Ports | 10 × USB Ports | |
| Reliability | Hardware Programmable Watchdog Timer, One-Key CMOS Clear | |
| Mechanical & Power | Power Input | 12V DC Input |
| Dimensions | 170*170mm | |
| Operating Temp | 0 ~ 60 °C (Industrial Standard) | |
| Supported OS | Windows 10, Windows 11, Linux (Ubuntu, CentOS) |
Downloads
No download files are attached to this product. You can request documents from our engineers.
Frequently Asked Questions
Technical specifications, OS compatibility, and deployment details for this platform
What processor and memory are listed for AX86M-LV62-HM86?
Processor: Intel® I5-43000M 2.6GHz 2 Cores / 4 Threads Processor; Memory: 2×SO-DIMM DDR3 memory, Up to 16GB
What interfaces are listed for AX86M-LV62-HM86?
Network: 2 × Gigabit Ethernet RJ45 ports(Single-LAN optional); Display: LVDS/EDP1+VGA/EDP2+HDMIDisplay
What operating conditions and software are listed for AX86M-LV62-HM86?
Power input: 12V DC Input; Operating temperature: 0 ~ 60 °C (Industrial Standard); Operating system: Windows 10, Windows 11, Linux (Ubuntu, CentOS)
